Congratulations to Chief Tony Laws, committee chairman Barry Jones and the members of the South Toe Fire & Rescue Department of Yancey County, Burnsville, NC, on the recent delivery of their 2014 International / 4 Guys pumper....
It is built on a 7600 series International with a 475 h.p. MaxxForce 13 diesel engine. It has an Allison 4000 EVS transmission and an 18,000 front axle and 30,000 rear axle. It has a driver controlled wheel differential lock. It has dual remote control and heated mirrors and an adjustable telescoping tilt steering wheel. On-Spot snow chains are included. Also included is a Kussmaul 1000 charging system with auto eject. It is dressed out with polished aluminum wheels with Real Wheels stainless steel wheel trim kits.
The pump is a Hale QMax XS 1500 g.p.m. single stage, side control panel, with a mechanical seal. It has two Hale anodes installed in the pump. It has two Hale manual MIV’s in the 6” left and right suctions. All valves are Akron 8000 heavy duty valves with a 10 year warranty. It has three 1 ½” discharges with 2” plumbing, two speedlays and one trash line in the right side running board. It has two left side 2 ½” pump panel discharges. It has one 2 ½” and one Akron electric 4” x 5” Storz discharge on the right pump panel. It has two rear discharges, one 3” with a 4” Storz adapter and a 2 ½”. It is equipped with a 3" pre-piped water way with an Akron 3440 Electronic Deck Master remote controlled deck gun with a 12” electric extension. This is controlled with an Akron electric valve with a flow meter. This pumper includes a Hypro Foam Pro 1600 Class A foam system. All gauges are backlit and color coded. The pump panel includes a compartment for a radio head and microphone.
The water tank is an 1875 gallon UPF poly tank with 20 gallon Class A foam cell. It has an electric rear Newton 10” stainless steel dump valve with a stainless steel extension. It is equipped with an air operated 1 ½” jet assist controlled from the cab. It also has two 10” Newton side dumps with 18” stainless steel extensions with painted stainless steel covers. It has a 3" rear tank fill and a 5” rear tank fill with a TFT Storz ball valve fill. It has an 8” vent/overflow. It has water level gauges on both right and left pump panels, and the rear of the truck and a mini gauge in the cab.
The body is all 12 gauge 304 grade stainless steel and has 4 Guys famous 30 year warranty. It has seven compartments, including two full height left side compartments, two high side compartments, one lower rear compartment and two right low side compartments. The ladders are stored in the hose bed. It carries three hard suction hose and pike poles, two are all stored in the body compartments and one over the dump tank. Included is a pull out tray and two adjustable shelves. It also has four double spare SCBA bottle compartments to carry eight spare bottles. The 2100 gallon Fol-Da-Tank is carried in a Zico PTS-HA portable hydraulic storage system with a painted stainless steel covered rack on the right side.
A Harrison 6 KW hydraulic generator is mounted in the dunnage area on the right. It has six Fire Research Spectra LED lights in the body, two on each side and two in the rear. It also has two Fire Research Spectra LED lights on telescoping poles, one at each pump panel. The one on the right is on a removable tripod. The one on the left is 12 volt. There is one Hannay electric cable reel with electric rewind and 200’ of 10/3 cable and a four outlet junction box. All the emergency red lights are Whelen LED's. All emergency and tail lights are M series. It has a Federal Q2B flush mounted siren in a custom front bumper extension.
Due to their station door height and inside length requirements, this apparatus had to be custom designed. It is 28’ – 7” long and 116” high. This is truly a custom built truck on a commercial chassis. The DuPont Imron 6000 paint carries a 10 year warranty. It was sold by Doug Callan, Cove Creek Fire Trucks, Greeneville, TN.
The pump is a Hale QMax XS 1500 g.p.m. single stage, side control panel, with a mechanical seal. It has two Hale anodes installed in the pump. It has two Hale manual MIV’s in the 6” left and right suctions. All valves are Akron 8000 heavy duty valves with a 10 year warranty. It has three 1 ½” discharges with 2” plumbing, two speedlays and one trash line in the right side running board. It has two left side 2 ½” pump panel discharges. It has one 2 ½” and one Akron electric 4” x 5” Storz discharge on the right pump panel. It has two rear discharges, one 3” with a 4” Storz adapter and a 2 ½”. It is equipped with a 3" pre-piped water way with an Akron 3440 Electronic Deck Master remote controlled deck gun with a 12” electric extension. This is controlled with an Akron electric valve with a flow meter. This pumper includes a Hypro Foam Pro 1600 Class A foam system. All gauges are backlit and color coded. The pump panel includes a compartment for a radio head and microphone.
The water tank is an 1875 gallon UPF poly tank with 20 gallon Class A foam cell. It has an electric rear Newton 10” stainless steel dump valve with a stainless steel extension. It is equipped with an air operated 1 ½” jet assist controlled from the cab. It also has two 10” Newton side dumps with 18” stainless steel extensions with painted stainless steel covers. It has a 3" rear tank fill and a 5” rear tank fill with a TFT Storz ball valve fill. It has an 8” vent/overflow. It has water level gauges on both right and left pump panels, and the rear of the truck and a mini gauge in the cab.
The body is all 12 gauge 304 grade stainless steel and has 4 Guys famous 30 year warranty. It has seven compartments, including two full height left side compartments, two high side compartments, one lower rear compartment and two right low side compartments. The ladders are stored in the hose bed. It carries three hard suction hose and pike poles, two are all stored in the body compartments and one over the dump tank. Included is a pull out tray and two adjustable shelves. It also has four double spare SCBA bottle compartments to carry eight spare bottles. The 2100 gallon Fol-Da-Tank is carried in a Zico PTS-HA portable hydraulic storage system with a painted stainless steel covered rack on the right side.
A Harrison 6 KW hydraulic generator is mounted in the dunnage area on the right. It has six Fire Research Spectra LED lights in the body, two on each side and two in the rear. It also has two Fire Research Spectra LED lights on telescoping poles, one at each pump panel. The one on the right is on a removable tripod. The one on the left is 12 volt. There is one Hannay electric cable reel with electric rewind and 200’ of 10/3 cable and a four outlet junction box. All the emergency red lights are Whelen LED's. All emergency and tail lights are M series. It has a Federal Q2B flush mounted siren in a custom front bumper extension.
Due to their station door height and inside length requirements, this apparatus had to be custom designed. It is 28’ – 7” long and 116” high. This is truly a custom built truck on a commercial chassis. The DuPont Imron 6000 paint carries a 10 year warranty. It was sold by Doug Callan, Cove Creek Fire Trucks, Greeneville, TN.
